CNC horizontal spindle circular table grinding machine

Each mechanism of the machine, as well as the main engine seat, slide saddle, column and spindle seat are numerically simulated (CFD).
And finite element method (FEA) analysis.
High rigidity hydrostatic rotary table, static rigidity ≥400kg/um, high running stability.
The hydrostatic turntable drive system is equipped with an accumulator to avoid contact wear caused by power failure or pressure loss.
High precision roller linear guide and high precision ball screw are installed on the Y and Z axes
The back backlash is eliminated and the screw tail end is pre-drawn to enhance the transmission rigidity.
Specially designed and developed grinding software with rich functions, easy operation and friendly man-machine interface.
