CG-A series oblique CNC cylindrical grinding machine

The grinding wheel spindle adopts non-contact static and dynamic bearing design with high rigidity and low temperature rise, and the spindle rotation accuracy is up to 0.001mm
A mechanical spindle equipped with high precision angular contact spindle bearings is available.
→ Electric spindles equipped with CBN grinding wheels for high precision and high efficiency grinding are available.
Workpiece spindle:
→ The workpiece spindle is driven by variable frequency or servo motor, which can provide more accurate speed setting.
A spindle can be rotated with or without a core to meet a variety of processing needs.
An optional work spindle with C-axis provides high precision machining of parts with non-circular lines.
