AHD/WM1/WM2 series program controlled surface grinding machine

Grinding program:
Semi-automatic grinding, automatic grinding, automatic trimming and other dialogue parameters input screen.
Drop down type up and down feed amount, easy to click, can be modified at any time during processing.
Front and back feeding mode: left, right, two sides, Z type, optional.
The front and back travel can be taught by single touch input.
* Grinding wheel automatic dressing automatic compensation:
Set the dressing time to automatically insert dressing, but also single action forced dressing.
The amount of grinding wheel dressing is automatically compensated to the machining program.
* Grinding wheel constant linear speed function:
Spindle frequency converter, after the grinding wheel dressing becomes smaller, according to the set grinding wheel line speed,
The grinding wheel automatically increases the speed.
Automatic machining and automatic trimming process, display program running status and information.
With fault self-diagno
