PC/PC2 series CNC surface grinding machine

Standard with a variety of grinding programs: semi-automatic, automatic, grooving, grooving, etc.
Groove grinding mode with unequal depth and width can be set.
Drop down type up and down feed amount, easy to click, can be modified at any time during processing.
Front and back feeding mode: left, right, two sides, Z type, optional.
The front and back travel can be taught by single touch input.
Automatic processing of 1-99 wide grooves or multi-grooves with equal spacing.
Grinding wheel dressing program: the bottom side, front side and back side can be dressed in tandem.
Set the dressing time to automatically insert dressing, but also single action forced dressing.
The amount of grinding wheel dressing is automatically compensated in the machining program.
Automatic machining and automatic trimming process, display program running status and information.
With fault self-diagnosis function, alarm screen automatically displays alarm tips.
User setting param
